een hele goede morgen heren, bij deze mijn set up
ik ben echt film liefhebber en stel daarom iets andere eisen aan mijn geluids systeem.
mijn muziek voorkeur gaat uit naar alles tussen trance en hardcore.
ook hier heb ik dus niets aan een heel verfijnd systeem.
mijn dvd speler is een oppo dv-981hd.(erg onbekend maar ben er heel tevreden over)
spec's
Features:
Universal DVD Player Features:
DVD-Audio, Super Audio CD (SACD) and DVD-Video universal playback
Compatible with Audio CD, HDCD, WMA, Kodak Picture CD, and other digital audio/video/picture media and formats* (*Note: The DV-981HD does not play Blu-Ray nor HD-DVD discs)
Official DivX® Certified product, certified to the Home Theater Profile
Plays all versions of DivX® video (including DivX® 6) with standard playback of DivX® media files
Plays XviD and .SRT, .SMI, .IDX and .SUB format
Compatible with CD-R/RW, DVD±R/RW and DVD+R DL* (*Note: Compatibility with user-encoded contents or user-created discs is on a best effort basis with no guarantee due to the variation of media, software and techniques used. For example, Discs recorded on some stand-alone DVD recorders or DVD camcorders may not exhibit smooth playback. )
Video Up-Conversion Features:
High definition up-conversion with film-like picture quality to up-convert 720x480 interlaced video encoded on DVD discs to 480p/720p/1080i and 1080p
DCDi by Faroudja video processing technology with progressive scan, film mode detection, TrueLife™ enhancement and motion adaptive noise reduction.
Video is analyzed on a single pixel granularity to detect presence or absence of angled lines and edges, which are then processed to produce a smooth natural looking image without visible artifacts (jaggies)
High-quality pure digital video and audio through a single HDMI (High Definition Multimedia Interface) cable
Multiple high definition video formats through HDMI output: NTSC: 480p/720p/1080i/1080p; PAL: 576p/720p/1080i/1080p
Compatible with HDTV, HD-Ready TV, HDTV monitors and projectors with an HDMI or DVI input
Direct PAL/NTSC disc and TV compatibility and system conversion
For more information about DVD video up-conversion, please read our white paper article Getting the Most out of DVD on an HDTV Display
Supports screen aspect ratio 4:3 (standard) and 16:9 (wide-screen)
User adjustable video controls: Sharpness, Contrast, Brightness, and Saturation
Composite video and S-Video outputs (standard-definition output only)
Optimized Audio Features:
High-resolution multi-channel digital audio output through HDMI supporting CD, DVD-Audio, SACD, Dolby Digital and DTS sound tracks.
Individual analog 5.1-channel surround and down-mixed stereo outputs
24-bit, 192kHz high resolution audio D/A converters
Optical and coaxial digital audio outputs with DTS, Dolby Digital, Dolby Pro-Logic II and Linear PCM support
3D Surround (Virtual Surround): Concert, Live, Dance, Techno, Classic, Soft
Built-in equalizer, channel trim and channel delay functions
Compatibility Features:
PAL/NTSC disc and TV compatible with automatic or manual system conversion
Dual-laser optical pickup head with excellent error correction
Enhanced dual-layer disc support with fast layer change
Wide range universal power supply (~100V-240V, 50/60Hz AC)
Convenience Features:
Special disc tray - thin, flexible and strong. Can tolerate some bending without breaking.
Smooth and easy navigation of photo albums, music collections and video files on DVD and CD
Selectable subtitle and audio tracks
Discrete ON/OFF remote control IR code for programmable universal remote controls
Connectors:
HDMI - High Definition Multimedia Interface: 1
Analog Stereo Audio (Mixed 2-Channel Left/Right): 1 group (2 connectors)
Analog 5.1 Channel Audio: 1 group (6 connectors)
S/PDIF (IEC-958) Coaxial Digital Audio: 1
S/PDIF (IEC-958) Optical Digital Audio: 1
Composite Video: 1
S-Video: 1
No Component Video (YPbPr/YCbCr) on the DV-981HD model. This model is designed for use with a display device with HDMI or DVI digital video input.
Accessories Included:
High-quality certified HDMI cable with gold-plated HDMI connectors
Remote control with "glow in the dark" keypad (batteries included)
Stereo audio cable
Composite video cable
User manual and warranty information
Specifications:
Designs and specifications are subject to change without notice.
Disc Types:
DVD-Video, DVD-Audio, Super Audio CD (SACD), DivX®, XviD, Audio CD, HDCD, Kodak Picture CD* (*Note: The DV-981HD does not play Blu-Ray nor HD-DVD discs)
Official DivX® Certified product, certified to the Home Theater Profile
Plays all versions of DivX® video (including DivX® 6) with standard playback of DivX® media files with encoded video resolution up to 720x480 30fps and 720x576 25fps
CD-R/RW, DVD+R/RW, DVD-R/RW, DVD+R DL* (*Note: Compatibility with user-encoded contents or user-created discs is on a best effort basis with no guarantee due to the variation of media, software and techniques used. For example, Discs recorded on some stand-alone DVD recorders or DVD camcorders may not exhibit smooth playback. )
Output:
Analog Audio: Stereo, 5.1ch
Digital Audio: Coaxial, Optical, HDMI
Analog Video: Composite, S-Video (Y/C) - standard-definition output only
Digital Video: HDMI with HDCP (NTSC 480p/720p/1080i/1080p, PAL 576p/720p/1080i/1080p)
No Component Video Output. The DV-981HD is designed for use with a display device with HDMI or DVI digital video input.
Video Characteristics:
HDMI: HDMI Specifications 1.1, CEA-861-B
S-Video Amplitude: Y: 1.0Vp-p (75 Ohm), C: 0.286Vp-p (75 Ohm)
Composite Video Amplitude: 1.0Vp-p (75 Ohm)
Audio Characteristics (Nominal specification):
Frequency: 20Hz – 20kHz (+/-1dB)
Signal-to-Noise Ratio: >100dB
Total Harmonic Distortion: < 0.01%
General Specification:
Power Supply: ~ 100V – 240V, 50/60Hz AC
Power Consumption: 20W
Dimensions: 420mm x 270mm x 41mm, 16-1/2 x 10-5/8 x 1-5/8 inches
Mass: 2.4kg / 5.20 lbs (DVD player unit only)
Operating Temperature:
5°C - 35°C
41°F - 95°F
Operating Humidity:
15% - 75% No condensation
Firmware Updates:
Upgradeable via CD-ROM
*DivX, DivX Certified, and associated logos are trademarks of DivX, Inc. and are used under license.
mijn versterker een denon avr-2801
spec's
Denon Denon AVR-2801 specifications
General Product Type AV receiver Width 17.1 in Depth 16.4 in Height 6.7 in Weight 25.4 lbs Enclosure Material Metal , Plastic , Aluminum Available Body Colors Black, gold Localization English Audio System Sound Output Mode Surround Sound Built-in Decoders DTS decoder , Dolby Digital , Dolby Pro Logic Digital Sound Processor (DSP) Yes Surround System Class 5.1 channel Input Channel Qty 6.0 Output Channel Qty 5.0 Output Power / Total 540.0 Watt Input Impedance 47.0 KOhm Input Sensitivity 200.0 mV Amplifier Output Details 90.0 Watt - 8.0 Ohm - THD 0.05 % - 2.0 channel(s) ( Surround ) , 90.0 Watt - 8.0 Ohm - THD 0.05 % - 1.0 channel(s) ( Center ) , 90.0 Watt - 8.0 Ohm - THD 0.05 % - 2.0 channel(s) ( Front ) Bass Control Yes Treble Control Yes Built-in Display Fluorescent Additional Features Digital signal format auto detection / auto switching , A-B speaker switch , Jog dial , On-screen display Radio Type Radio tuner - AM/FM - Digital Tuner Frequency Range 520 - 1710 kHz , FM: 87.5 - 108 MHz Tuning Display Fluorescent display Preset Station Qty 40.0 Antenna Form Factor Loop AM / wire FM Station Memo Display Yes Auto Preset Memory Yes Turntable Type None CD System CD system type None DVD Type None Cassette System Cassette system type None Digital Player (Recorder) Type None MD System MD system type None Headphones Headphones Type None Microphone Type None Remote Control Remote Control Universal remote control - Infrared Supported Devices Cassette deck , CD player / changer , TV , VCR , DVD player , LD player , MD player Features Color-coded buttons , Macro function , Remote confirmation , Learning , Glow buttons Miscellaneous AV Furniture None Connections Connector Type 7.0 x S-Video output ( 4 pin mini-DIN ) - Rear , 1.0 x Audio line-out ( RCA phono x 2 ) - Rear , 3.0 x Composite video input ( RCA phono x 6 ) - Rear , 1.0 x SPDIF input ( RCA phono ) - Rear , 1.0 x 5.1 channel audio line-out ( RCA phono ) - Rear , 5.0 x 5.1 channel audio line-in ( RCA phono x 2 ) - Rear , 1.0 x SPDIF input ( Phone stereo 6.25 mm ) - Rear , 5.0 x Speakers output ( Banana/spade x 2 ) - Rear , 9.0 x S-Video input ( 4 pin mini-DIN ) - Rear , 3.0 x Headphones ( RCA phono x 6 ) - Front , 3.0 x Audio line-in ( RCA phono ) - Rear , 3.0 x Composite video output - Rear Power Power Device Power supply - Integrated Power ± 10% ( 50 Hz ) Power Consumption Operational 270.0 Watt

CERWIN-VEGA! cls-6 ACHTER SPEAKER'S
6-1/2” 2-Way Bookshelf Speaker
(Preliminary specifications subject to change.)
Perfect for environments where space is at a premium, the CLS-6 is a two-way bookshelf, featuring a single 6 1/2 – inch fiber impregnated woofer and a 1-inch soft dome tweeter with a proprietary waveguide.
• Frequency Response: 50 Hz - 20 kHz
• Peak Power Handling: 125 watts
• Sensitivity (1w/1m): 90 dB
• 6 1/2" Woofer with Fiber Impregnated Cone
• 1" Soft Dome Tweeter with Ferro Fluid
• Proprietary Mid and High Frequency Waveguide
• High Frequency Protection
• Video Sheilding
• Elegant Black-Ash Enclosure
DIMENSIONS
Dimensions (HxWxD): 15.4" x 8" x 10.45"
Weight: 20 lbs.
CERWIN-VEGA! VE-12 VOOR SPEAKER'S
12" 3-Way Tower
(Preliminary specifications subject to change.)
The large, 3-way designs with Bass Reflex and 12-inch woofer, respectively, kick out the high volume and articulated bass that have made Cerwin-Vega famous. They’re perfect for everything from the tight definition of mid- and high-frequency rock and jazz to the deep bass of hip-hop and R&B.
• Frequency Response: 28 Hz - 20 kHz
• Peak Power Handling: 300 watts
• Sensitivity (1w/1m): 93 dB
• 5 1/4" Midrange with Fiber Impregnated Cone
• 1 1/4" Treated Silver Mylar Tweeter with Ferro Fluid
• 12" Cast Frame High Excursion Woofer
• Protection: Self Resetting, PTC (tweeter), Fuse (woofer)
• Elegant Black-Ash Enclosure
DIMENSIONS
Dimensions (HxWxD): 33” x 16” x 14.1”
Weight: 51 lbs.
JBL CENTER SPEAKER
mijn center speaker is een jbl ik kan geen type vinden maar ik dacht dat het een 100 watt type was en de reden dat ik naar iets anders op zoek was als 1 van cerwin-vega! is dat die aleen 2 weg centers leveren en ik vind dat ie frequentie niet ver genoeg uit elkaar lag.
en deze 3 weg jbl doet precies wat ie moet doen.
deze spike's heeft ronnie voor me gedraaid, 3 per speaker.
ze staan in losse kommen en die staan weer op een kurken onderlaag.
in mijn kabels is zeker ruimte voor verbetering.
het zijn 4 kwadraats kabels gewoon koper,ik wil er ooit wel wat anders voor maar vergeet niet dat je bij 5.1 veel meter kabels hebt.
SUBWOOFER
heb ik niet dit is in te stellen op mijn dvd speler.
want met 2x12 inch woofers heb je bas genoeg.
heb wel eens een sub hier gehad, maar vind de meerwaarde te klein heb al genoeg speakers in de kamer!
ik overleg wel eens met mijn buurman als ik overdag een oorlog film op max wil gaan kijken.
van cerwin-vega! kan ik niet zeggen dat het allemaal even zuiver is op alle volumes maar je hebt wel een harde strakke weergave van het geluid.
ik hoop ooit mijn vriendin zo ver te krijgen dat ik de voorspeakers mag wisselen voor de cls-12 maar daar zie je de rode rand door de covers heen en dat wil ze niet.
ik luister dit in de kamer van 4x7 meter in de breedte van de kamer dus een stuk van 4x4 meter.
TV(nog)een glasbak.
gr maurice
